Product Overview
Exterior aluminum sliding doors share the sliding structure with glass sliding doors but differ in sash design and application. These doors use lighter sashes and are intended for outdoor entrances with frequent passage and moderate daylight requirements.
These doors are used in hotel service passage doors, residential balcony sliding doors, commercial outdoor passage doors, and public building entrances.
Core Advantages
Lightweight sash for frequent passage:
The sash design is optimized for weight reduction. In hotel service passages and public building entrances where doors are opened frequently, this reduces the effort required for daily operation.
Anti-sway track design:
An anti-sway device is configured in the track system. In outdoor entrances exposed to wind, this keeps the sash from swinging forward and backward, so the door runs in a stable line.
Panel options for different daylight needs:
The sash can be configured with tempered glass or aluminium panels. In service passages where daylight is not the main requirement, aluminium panels can be used; in balcony areas, glass panels can be selected.
Sealing for outdoor use:
EPDM sealing strips and automotive-grade sealing strips are used with a dedicated sliding roller and latch lock system.
Applications
• Hotel service passage doors
• Residential balcony sliding doors
• Commercial outdoor passage doors
• Public building entrances
Specifications
|
Item |
Standard Configuration |
|
Profile material |
6063-T5 aluminium |
|
Profile wall thickness |
1.8–2.2 mm (customizable) |
|
Frame width |
80–120 mm (customizable) |
|
Panel configuration |
Tempered glass / aluminium panel (as required) |
|
Surface treatment |
Electrostatic powder coating / fluorocarbon powder coating |
|
Hardware |
Dedicated sliding door rollers, handle, latch lock |
|
Sealing strip |
EPDM / automotive-grade sealing strip |
OEM/ODM
Exterior aluminum sliding doors support OEM and ODM. Production can follow drawings or sample prototypes. Colors and models can be mixed. Sample development lead time is about 10–15 working days with existing material stock. Standard products carry a 10-year warranty.
■ Customizable Items
Profile wall thickness
Frame width
Panel type: tempered glass or aluminium panel
Surface treatment and color
Hardware configuration
Screen door integration: 304 stainless steel diamond mesh or nylon mesh
Quality Control
Profile and panel dimensions are checked on incoming material. The anti-sway device and roller system are inspected before assembly.
After assembly, each door is tested for sliding operation and anti-sway function. A 100% inspection is performed before shipment. Third-party inspection is supported.
FAQ
Q: Does the track system on exterior aluminum sliding doors have an anti-sway design?
A: Yes. An anti-sway device is configured in the track system to keep the sash from swinging forward and backward during operation.
Q: Can product be made with an integrated screen door?
A: Yes. 304 stainless steel diamond mesh or nylon mesh can be configured to combine the sliding door and screen door in one system.
