Product Overview
Large aluminium sliding doors are designed for large openings and large glass panels. The sash dimensions and track system are reinforced for wide openings.
These doors are used in villa large balcony doors, commercial showroom entrances, hotel lobby passages, and high-end residential living room exterior doors.
Core Advantages
Reinforced profile for large sashes:
The door uses reinforced 6063-T5 aluminium profiles with wall thickness from 1.8 mm to 2.2 mm and frame width from 80 mm to 120 mm. In villa balconies and showroom entrances with wide openings, this supports the structural rigidity required for large sashes.
Track system for large sash weight:
A heavy-duty sliding roller system is used. In hotel lobby passages and commercial showroom entrances where large sashes are moved frequently, the roller system is selected for the sash weight and frequency of use.
Stable operation at large dimensions:
The track system rigidity and roller load capacity are matched to the sash size. In commercial lobby entrances, the sash remains stable during sliding without swaying or sagging.
Glass configuration for large panels:
Standard glass is 5 mm + 12A + 5 mm tempered insulated glass. The thickness can be adjusted according to sash size and project requirements.
Applications
Villa large balcony doors
01
Commercial showroom entrances
02
Hotel lobby passages
03
High-end residential living room exterior doors
04
Specifications
|
Item |
Standard Configuration |
|
Profile material |
6063-T5 aluminium (reinforced) |
|
Profile wall thickness |
1.8–2.2 mm (customizable) |
|
Frame width |
80–120 mm (customizable) |
|
Glass configuration |
5 mm + 12A + 5 mm tempered insulated (other thicknesses available) |
|
Surface treatment |
Electrostatic powder coating / fluorocarbon powder coating |
|
Hardware |
Heavy-duty sliding rollers, handle, latch lock |
|
Sealing strip |
EPDM |
OEM/ODM
Large aluminium sliding doors support custom large sash sizes to drawings. Profile supplier resources cover mainstream domestic suppliers. Profile wall thickness and hardware configuration can be adjusted according to project requirements.
■ Customizable Items
• Sash dimensions
• Profile wall thickness
• Frame width
• Glass configuration and thickness
• Surface treatment and color
• Hardware configuration
• Mixed colors and models within one order
Quality Control
Profile dimensions and wall thickness are checked on incoming material. Track straightness and roller fit are inspected before assembly.
After assembly, each door is tested for sliding operation under load. A 100% inspection is performed before shipment. Third-party inspection is supported.
FAQ
Q: What is the maximum sash size for large aluminium sliding doors?
A: The specific size is determined by the project drawing and profile matching solution. The engineering team evaluates track load capacity and profile rigidity before confirming the sash size.
Q: What is the roller service life for large sashes?
A: A heavy-duty sliding roller system is used, selected for the weight and frequency of large sashes to maintain sliding smoothness and stability over long-term use.
