Product Overview
Aluminium sheet wall cladding is an aluminium panel cladding system for exterior wall protection and decoration. The aluminium panel works with a framing structure to form a continuous decorative and protective layer on the building exterior surface. The cladding system isolates the building wall from external environmental exposure and gives the facade a consistent visual effect.
These systems are used in building exterior wall cladding, commercial building facade decoration, industrial factory exterior walls, public building exteriors, and building renovation projects.
Core Advantages
Bent overlap structure for water management:
The panel is bent to form an overlap structure. Combined with sealant and a waterproof layer design, the cladding system manages water at the panel joints. In building exterior wall cladding exposed to rain, the overlap structure directs water away from the wall substrate.
Panel thickness for exterior cladding duty:
The panel uses 3003 aluminium sheet with a thickness of 2–3 mm and a fluorocarbon coating thickness of 40–60 μm. In commercial building facade decoration and industrial factory exterior walls, the panel thickness is selected for exterior cladding duty.
Low weight for renovation projects:
Aluminium cladding panels are lightweight. In building renovation projects, the low panel weight reduces the load requirement on the existing building substrate.
Framing and connection fittings supplied together:
The cladding system is supplied with framing and connection fittings. In building exterior wall cladding projects, this allows the panel and support system to be matched from one supplier.
Applications
• Building exterior wall cladding
• Commercial building facade decoration
• Industrial factory exterior walls
• Public building exteriors
• Building renovation projects
Specifications
|
Item |
Standard Configuration |
|
Sheet material |
3003 aluminium |
|
Sheet thickness |
2–3 mm (customizable) |
|
Surface treatment |
Fluorocarbon coating (coating thickness 40–60 μm) |
|
Fire rating |
A-grade non-combustible |
|
Common size |
1220×2440 mm large sheet (customizable) |
|
Performance |
Waterproof, moisture-resistant, lightweight |
OEM/ODM
Aluminium sheet wall cladding supports custom sheet dimensions and bending shapes according to the building facade drawing. Framing and connection fittings are supplied together. Colours are customizable, and irregular sizes are supported.
■ Customizable Items
• Sheet thickness
• Sheet dimensions
• Bending shape
• Framing and connection fittings
• Colour
• Surface treatment: fluorocarbon coating or powder coating
Quality Control
Sheet thickness and coating thickness are checked on incoming material. Bending dimensions and overlap structure are inspected before assembly.
Panel flatness and coating adhesion are checked before shipment. A protective film is applied to the surface before packing. Third-party inspection is supported.
FAQ
Q: How is the waterproof performance of aluminium sheet wall cladding ensured?
A: The panel is bent to form an overlap structure, combined with sealant and a waterproof layer design to ensure the overall waterproof performance of the cladding system. Installation nodes need to be constructed according to the specification.
Q: Can cladding aluminium panels be used for old building renovation?
A: Yes. The aluminium cladding system is lightweight and has low load requirements on the building substrate, making it suitable for old building facade renovation. Sheet dimensions can be customized according to actual site conditions.
